美孚润滑油系列 > 液压油 > 美孚DTE FM食品级液压油



美孚DTE FM食品级液压油 详细说明 (浏览2467次)
Mobil DTE FM 详细信息:

Mobil DTE FM Series Pdf
Food Machinery Lubricants Print View
Product Description Features and Benefits Applications Specifications and Approvals Typical Properties Health and Safety

Product Description

Mobil DTE FM Series oils are high performance lubricants designed to satisfy a wide range of multi-use equipment requirements for the food processing and packaging industry. These lubricants are qualified as NSF H1 type lubricants and also comply with Title 21 CFR 178.3570 by the Food and Drug Administration (USA) for lubricants with incidental food contact. The lubricants are tasteless, odourless, premium quality lubricants formulated with non-toxic NSF/FDA food grade additives and base oils. The additive system provides good wear protection, excellent oxidation stability and protection against rust. They provide good system cleanliness, long oil/filter life, and optimum equipment protection. The Mobil DTE FM Series oils are excellent gear, bearing and circulating oils. They are also suitable for handling the critical requirements of hydraulic system components such as close clearance servo-valves and the high accuracy numerically controlled (NC) machine tools. These products meet the most rigorous performance requirements of a wide range of system and component manufacturers using various multi-metallurgy designs allowing a single product with outstanding performance characteristics.

The Mobil DTE FM Series oils have high ratings in the FZG Gear Test demonstrating their excellent protection against wear and scuffing. This allows their use in systems other than hydraulics that may contain gears and bearings. The naturally high viscosity index of the base oils ensures outstanding performance over a wide temperature range.



Features and Benefits




Features

Advantages and Potential Benefits
Non-Toxic Formulation Allows use in food packaging and processing applications
Very Good Anti-wear Properties Reduces wear
Extends equipment life
Excellent Oxidation Stability Provides long oil and equipment life
Extends filter life
High Level Corrosion Protection Prevents internal hydraulic system corrosion
Reduces negative effects of moisture in systems
Provides corrosion protection of multi-metallurgy component designs
Meets a Wide Range of equipment requirements Multi-service applications - One product can replace several
Minimises inventory requirements
Reduced potential for product misapplication
Excellent Air Separation Characteristics Reduces foaming and it's negative effects
Very Good Water Separation Properties Protects systems where small quantities of moisture are present
Readily separates larger quantities of water

Applications

  • Suitable for multi-service applications in the lubrication of machinery used in all food processing industries, fish processing and met packing plants
  • Excellent gear, bearing, circulating system and hydraulic oils
  • Compressors and vacuum pumps handling air and inert gasses
  • Air line lubricators
  • Systems requiring a high degree of load-carrying capability and anti-wear protection
  • Mobil DTE FM 220, 320 and 460 are recommended for freezer plants and for outdoor applications due to their low temperature properties and high temperature stability
  • Machines employing a wide range of components using various metallurgy



Back to Top

Specifications and Approvals

Meets or Exceeds the following industry specifications

Mobil DTE FM 32

Mobil DTE FM 46

Mobil DTE FM 68

Mobil DTE FM 100

Mobil DTE FM 150
FDA 21 CFR 178.3570 X X X X X
NSF H1 X X X X X

Meets or Exceeds the following industry specifications

Mobil DTE FM 220

Mobil DTE FM 320

Mobil DTE FM 460

Mobil DTE FM 680
FDA 21 CFR 178.3570 X X X X
NSF H1 X X X


Typical Properties


Mobil DTE FM 32

Mobil DTE FM 46

Mobil DTE FM 68

Mobil DTE FM 100

Mobil DTE FM 150
ISO Grade 32 46 68 100 150
Viscosity, ASTM D 445
cSt @ 40º C 31.9 45.5 68.5 96.7 155.5
cSt @ 100º C 5.5 6.8 8.7 10.9 17.0
Viscosity Index, ASTM D 2270 106 105 101 97 118
Specific Gravity @ 15.6º C/15.6º C, ASTM D 4.52 0.862 0.868 0.873 0.878 0.869
Copper Strip Corrosion, ASTM D 130 1A 1A 1A 1A 1A
Rust Characteristics Proc. A, ASTM D 665 Pass Pass Pass Pass Pass
Pour Point, ºC, ASTM D 97 -12 -9 -12 -18 -12
Flash Point, ºC, ASTM D 92 212 226 228 246 250
FZG, DIN 51354, Fail Stage 11 12+ 12+ 12+ 12+
4-Ball wear, ASTM D 4172, Scar Dia, 20Kg, 54º C, 1800 rpm, 1 hr, mm 0.25 0.25 0.25 0.25 0.26


Mobil DTE FM 220

Mobil DTE FM 320

Mobil DTE FM 460

Mobil DTE FM 680
ISO Grade 220
Viscosity, ASTM D 445
cSt @ 40º C 214.3 325.8 439.5 670.0
cSt @ 100º C 24.5 34.2 43.4 61.2
Viscosity Index, ASTM D 2270 143 148 152 159
Specific Gravity @ 15.6º C/15.6º C, ASTM D 4.52 0.854 0.852 0.852 0.853
Copper Strip Corrosion, ASTM D 130 1A 1A 1A 1A
Rust Characteristics Proc. A, ASTM D 665 Pass Pass Pass Pass
Pour Point, ºC, ASTM D 97 -21 -30 -36 -39
Flash Point, ºC, ASTM D 92 246 272 284 278
FZG, DIN 51354, Fail Stage 12+ 12+ 12+ 12+
4-Ball wear, ASTM D 4172, Scar Dia, 20Kg, 54º C, 1800 rpm, 1 hr, mm 0.25 0.25 0.30 0.30
